de.lmu.ifi.dbs.elki.visualization
Class VisualizerContext

java.lang.Object
  java.util.AbstractMap<K,V>
      java.util.HashMap<K,Object>
          de.lmu.ifi.dbs.elki.utilities.datastructures.AnyMap<String>
              de.lmu.ifi.dbs.elki.visualization.VisualizerContext

All Implemented Interfaces:

DataStoreListener, Result, ResultListener, Serializable, Cloneable, EventListener, Map<String,Object>

public class VisualizerContext
extends AnyMap<String>
implements DataStoreListener, ResultListener, Result

Map to store context information for the visualizer. This can be any data that should to be shared among plots, such as line colors, styles etc.

See Also:

Serialized Form

Nested Class Summary

Nested classes/interfaces inherited from class java.util.AbstractMap

AbstractMap.SimpleEntry<K,V>, AbstractMap.SimpleImmutableEntry<K,V>

Field Summary

static String	CLUSTERING Identifier for the primary clustering to use.
static String	CLUSTERING_FALLBACK Identifier for a fallback (default) clustering.
private Collection<VisFactory>	factories Factories to use
private Pattern	hideVisualizers Visualizers to hide by default
private EventListenerList	listenerList The event listeners for this context.
private static Logging	logger Logger.
private Collection<ProjectorFactory>	projectors Projectors to use
private HierarchicalResult	result The full result object
static String	SELECTION Identifier for the selection
private static long	serialVersionUID Serial version.
private StyleLibrary	stylelib The style library of this context
static String	VISUALIZER_LIST Identifier for the visualizer list

Constructor Summary

VisualizerContext(HierarchicalResult result, StyleLibrary stylelib, Collection<ProjectorFactory> projectors, Collection<VisFactory> factories, Pattern hideVisualizers)
Constructor.

Method Summary

void	addContextChangeListener(ContextChangeListener listener) Add a context change listener.
void	addDataStoreListener(DataStoreListener l) Adds a listener for the DataStoreEvent posted after the content changes.
void	addResultListener(ResultListener listener) Register a result listener.
void	contentChanged(DataStoreEvent e) Proxy datastore event to child listeners.
void	fireContextChange(ContextChangedEvent e) Trigger a context change event.
private Clustering<Model>	generateDefaultClustering() Generate a default (fallback) clustering.
ResultHierarchy	getHierarchy() Get the hierarchy object
String	getLongName() A "pretty" name for the result, for use in titles, captions and menus.
Clustering<Model>	getOrCreateDefaultClustering() Convenience method to get the clustering to use, and fall back to a default "clustering".
HierarchicalResult	getResult() Get the full result object
DBIDSelection	getSelection() Get the current selection.
String	getShortName() A short name for the result, useful for file names.
StyleLibrary	getStyleLibrary() Get the style library
IterableIterator<VisualizationTask>	iterVisualizers() Deprecated. Odd semantics: contains duplicates!
private void	processNewResult(HierarchicalResult baseResult, Result newResult) Process a particular result.
void	removeContextChangeListener(ContextChangeListener listener) Remove a context change listener.
void	removeDataStoreListener(DataStoreListener l) Removes a listener previously added with addDataStoreListener.
void	removeResultListener(ResultListener listener) Remove a result listener.
void	resultAdded(Result child, Result parent) A new derived result was added.
void	resultChanged(Result current) Notify that the current result has changed substantially.
void	resultRemoved(Result child, Result parent) A result was removed.
void	setSelection(DBIDSelection sel) Set a new selection.
void	setVisualizationVisibility(VisualizationTask task, boolean visibility) Change a visualizers visibility.

Methods inherited from class de.lmu.ifi.dbs.elki.utilities.datastructures.AnyMap

get, get, getGenerics

Methods inherited from class java.util.HashMap

clear, clone, containsKey, containsValue, entrySet, isEmpty, keySet, put, putAll, remove, size, values

Methods inherited from class java.util.AbstractMap

equals, hashCode, toString

Methods inherited from class java.lang.Object

finalize, getClass, notify, notifyAll, wait, wait, wait

Methods inherited from interface java.util.Map

equals, hashCode

Field Detail

serialVersionUID

private static final long serialVersionUID

Serial version.

See Also:

Constant Field Values

logger

private static final Logging logger

Logger.

result

private HierarchicalResult result

The full result object

listenerList

private EventListenerList listenerList

The event listeners for this context.

stylelib

private StyleLibrary stylelib

The style library of this context

projectors

private Collection<ProjectorFactory> projectors

Projectors to use

factories

private Collection<VisFactory> factories

Factories to use

hideVisualizers

private Pattern hideVisualizers

Visualizers to hide by default

CLUSTERING

public static final String CLUSTERING

Identifier for the primary clustering to use.

See Also:

Constant Field Values

CLUSTERING_FALLBACK

public static final String CLUSTERING_FALLBACK

Identifier for a fallback (default) clustering.

See Also:

Constant Field Values

VISUALIZER_LIST

public static final String VISUALIZER_LIST

Identifier for the visualizer list

See Also:

Constant Field Values

SELECTION

public static final String SELECTION

Identifier for the selection

See Also:

Constant Field Values

Constructor Detail

VisualizerContext

public VisualizerContext(HierarchicalResult result,
                         StyleLibrary stylelib,
                         Collection<ProjectorFactory> projectors,
                         Collection<VisFactory> factories,
                         Pattern hideVisualizers)

Constructor. We currently require a Database and a Result.

Parameters:

result - Result

stylelib - Style library

projectors - Projectors to use

factories - Visualizer Factories to use

hideVisualizers - Pattern to hide visualizers

Method Detail

getResult

public HierarchicalResult getResult()

Get the full result object

Returns:

result object

getHierarchy

public ResultHierarchy getHierarchy()

Get the hierarchy object

Returns:

hierarchy object

getStyleLibrary

public StyleLibrary getStyleLibrary()

Get the style library

Returns:

style library

getOrCreateDefaultClustering

public Clustering<Model> getOrCreateDefaultClustering()

Convenience method to get the clustering to use, and fall back to a default "clustering".

Returns:

Clustering to use

generateDefaultClustering

private Clustering<Model> generateDefaultClustering()

Generate a default (fallback) clustering.

Returns:

generated clustering

getSelection

public DBIDSelection getSelection()

Get the current selection.

Returns:

selection

setSelection

public void setSelection(DBIDSelection sel)

Set a new selection.

Parameters:

sel - Selection

setVisualizationVisibility

public void setVisualizationVisibility(VisualizationTask task,
                                       boolean visibility)

Change a visualizers visibility. When a Tool visualizer is made visible, other tools are hidden.

Parameters:

task - Visualization task

visibility - new visibility

addContextChangeListener

public void addContextChangeListener(ContextChangeListener listener)

Add a context change listener.

Parameters:

listener -

removeContextChangeListener

public void removeContextChangeListener(ContextChangeListener listener)

Remove a context change listener.

Parameters:

listener -

fireContextChange

public void fireContextChange(ContextChangedEvent e)

Trigger a context change event.

Parameters:

e - Event

addDataStoreListener

public void addDataStoreListener(DataStoreListener l)

Adds a listener for the DataStoreEvent posted after the content changes.

Parameters:

l - the listener to add

See Also:

removeDataStoreListener(de.lmu.ifi.dbs.elki.database.datastore.DataStoreListener)

removeDataStoreListener

public void removeDataStoreListener(DataStoreListener l)

Removes a listener previously added with addDataStoreListener.

Parameters:

l - the listener to remove

See Also:

addDataStoreListener(de.lmu.ifi.dbs.elki.database.datastore.DataStoreListener)

contentChanged

public void contentChanged(DataStoreEvent e)

Proxy datastore event to child listeners.

Specified by:

contentChanged in interface DataStoreListener

Parameters:

e - the update event

processNewResult

private void processNewResult(HierarchicalResult baseResult,
                              Result newResult)

Process a particular result.

Parameters:

baseResult - Base Result

newResult - Newly added Result

iterVisualizers

@Deprecated
public IterableIterator<VisualizationTask> iterVisualizers()

Deprecated. Odd semantics: contains duplicates!

Get an iterator over all visualizers.

Returns:

Iterator

addResultListener

public void addResultListener(ResultListener listener)

Register a result listener.

Parameters:

listener - Result listener.

removeResultListener

public void removeResultListener(ResultListener listener)

Remove a result listener.

Parameters:

listener - Result listener.

resultAdded

public void resultAdded(Result child,
                        Result parent)

Description copied from interface: ResultListener

A new derived result was added.

Specified by:

resultAdded in interface ResultListener

Parameters:

child - New child result added

parent - Parent result that was added to

resultChanged

public void resultChanged(Result current)

Description copied from interface: ResultListener

Notify that the current result has changed substantially.

Specified by:

resultChanged in interface ResultListener

Parameters:

current - Result that has changed.

resultRemoved

public void resultRemoved(Result child,
                          Result parent)

Description copied from interface: ResultListener

A result was removed.

Specified by:

resultRemoved in interface ResultListener

Parameters:

child - result that was removed

parent - Parent result that was removed from

getLongName

public String getLongName()

Description copied from interface: Result

A "pretty" name for the result, for use in titles, captions and menus.

Specified by:

getLongName in interface Result

Returns:

result name

getShortName

public String getShortName()

Description copied from interface: Result

A short name for the result, useful for file names.

Specified by:

getShortName in interface Result

Returns:

result name
