de.lmu.ifi.dbs.elki.data
Class BitVector

java.lang.Object
  de.lmu.ifi.dbs.elki.data.AbstractNumberVector<BitVector,Bit>
      de.lmu.ifi.dbs.elki.data.BitVector

All Implemented Interfaces:

FeatureVector<BitVector,Bit>, NumberVector<BitVector,Bit>, SpatialComparable, ByteBufferSerializer<BitVector>

public class BitVector
extends AbstractNumberVector<BitVector,Bit>
implements ByteBufferSerializer<BitVector>

Provides a BitVector wrapping a BitSet.

Field Summary

private BitSet	bits Storing the bits.
private int	dimensionality Dimensionality of this bit vector.

Fields inherited from class de.lmu.ifi.dbs.elki.data.AbstractNumberVector

ATTRIBUTE_SEPARATOR

Constructor Summary

BitVector(Bit[] bits)
Provides a new BitVector corresponding to the bits in the given array.

BitVector(BitSet bits, int dimensionality)
Provides a new BitVector corresponding to the specified bits and of the specified dimensionality.

BitVector(List<Bit> bits)
Provides a new BitVector corresponding to the bits in the given list.

Method Summary

boolean	contains(BitSet bitset) Returns whether this BitVector contains all bits that are set to true in the specified BitSet.
double	doubleValue(int dimension) Returns the value in the specified dimension as double.
boolean	equals(Object obj) Indicates whether some other object is "equal to" this BitVector.
BitVector	fromByteBuffer(ByteBuffer buffer) Deserialize an object from a byte buffer (e.g. disk)
BitSet	getBits() Returns a copy of the bits currently set in this BitVector.
int	getByteSize(BitVector vec) Get the size of the object in bytes.
Vector	getColumnVector() Returns a Vector representing in one column and getDimensionality() rows the values of this BitVector as double values.
int	getDimensionality() The dimensionality of the binary vector space of which this BitVector is an element.
Matrix	getRowVector() Returns a Matrix representing in one row and getDimensionality() columns the values of this BitVector as double values.
Bit	getValue(int dimension) Returns the value in the specified dimension.
long	longValue(int dimension) Returns the value in the specified dimension as long.
BitVector	minus(BitVector fv) Returns a bit vector corresponding to an NXOR operation on this and the specified bit vector.
BitVector	multiplicate(double k) Returns a bit vector equal to this bit vector, if k is not 0, a bit vector with all components equal to zero otherwise.
BitVector	negativeVector() Returns the inverse of the bit vector.
BitVector	newInstance(Bit[] values) Creates and returns a new BitVector based on the passed values.
BitVector	newInstance(double[] values) Returns a new NumberVector of N for the given values.
BitVector	newInstance(List<Bit> values) Creates and returns a new BitVector based on the passed values.
BitVector	newInstance(Vector values) Returns a new NumberVector of N for the given values.
BitVector	nullVector() Returns a bit vector of equal dimensionality but containing 0 only.
BitVector	plus(BitVector fv) Returns a bit vector corresponding to an XOR operation on this and the specified bit vector.
Bit	scalarProduct(BitVector fv) Provides the scalar product (inner product) of this BitVector and the given BitVector.
void	toByteBuffer(ByteBuffer buffer, BitVector vec) Serialize the object to a byte array (e.g. disk)
String	toString() Returns a String representation of this BitVector.

Methods inherited from class de.lmu.ifi.dbs.elki.data.AbstractNumberVector

byteValue, floatValue, getMax, getMin, hashCode, intValue, shortValue

Methods inherited from class java.lang.Object

clone, finalize, getClass, notify, notifyAll, wait, wait, wait

Field Detail

bits

private BitSet bits

Storing the bits.

dimensionality

private int dimensionality

Dimensionality of this bit vector.

Constructor Detail

BitVector

public BitVector(BitSet bits,
                 int dimensionality)
          throws IllegalArgumentException

Provides a new BitVector corresponding to the specified bits and of the specified dimensionality.

Parameters:

bits - the bits to be set in this BitVector

dimensionality - the dimensionality of this BitVector

Throws:

IllegalArgumentException - if the specified dimensionality is to small to match the given BitSet

BitVector

public BitVector(Bit[] bits)

Provides a new BitVector corresponding to the bits in the given array.

Parameters:

bits - an array of bits specifying the bits in this bit vector

BitVector

public BitVector(List<Bit> bits)

Provides a new BitVector corresponding to the bits in the given list.

Parameters:

bits - an array of bits specifying the bits in this bit vector

Method Detail

getDimensionality

public int getDimensionality()

The dimensionality of the binary vector space of which this BitVector is an element.

Specified by:

getDimensionality in interface FeatureVector<BitVector,Bit>

Specified by:

getDimensionality in interface SpatialComparable

Returns:

the number of dimensions of this FeatureVector of V

See Also:

FeatureVector.getDimensionality()

getValue

public Bit getValue(int dimension)

Returns the value in the specified dimension.

Specified by:

getValue in interface FeatureVector<BitVector,Bit>

Parameters:

dimension - the desired dimension, where 1 ≤ dimension ≤ this.getDimensionality()

Returns:

the value in the specified dimension

See Also:

FeatureVector.getValue(int)

doubleValue

public double doubleValue(int dimension)

Returns the value in the specified dimension as double.

Specified by:

doubleValue in interface NumberVector<BitVector,Bit>

Parameters:

dimension - the desired dimension, where 1 ≤ dimension ≤ this.getDimensionality()

Returns:

the value in the specified dimension

See Also:

NumberVector.doubleValue(int)

longValue

public long longValue(int dimension)

Returns the value in the specified dimension as long.

Specified by:

longValue in interface NumberVector<BitVector,Bit>

Parameters:

dimension - the desired dimension, where 1 ≤ dimension ≤ this.getDimensionality()

Returns:

the value in the specified dimension

See Also:

NumberVector.longValue(int)

getColumnVector

public Vector getColumnVector()

Returns a Vector representing in one column and getDimensionality() rows the values of this BitVector as double values.

Specified by:

getColumnVector in interface NumberVector<BitVector,Bit>

Returns:

a Matrix representing in one column and getDimensionality() rows the values of this BitVector as double values

See Also:

NumberVector.getColumnVector()

getRowVector

public Matrix getRowVector()

Returns a Matrix representing in one row and getDimensionality() columns the values of this BitVector as double values.

Specified by:

getRowVector in interface NumberVector<BitVector,Bit>

Returns:

a Matrix representing in one row and getDimensionality() columns the values of this BitVector as double values

See Also:

NumberVector.getRowVector()

multiplicate

public BitVector multiplicate(double k)

Returns a bit vector equal to this bit vector, if k is not 0, a bit vector with all components equal to zero otherwise.

Specified by:

multiplicate in interface NumberVector<BitVector,Bit>

Parameters:

k - used as multiplier 1 if k ≠ 0, otherwise the resulting bit vector will have all values equal to zero

Returns:

a bit vector equal to this bit vector, if k is not 0, a bit vector with all components equal to zero otherwise

negativeVector

public BitVector negativeVector()

Returns the inverse of the bit vector. The result is the same as obtained by flipping all bits in the underlying BitSet.

Specified by:

negativeVector in interface NumberVector<BitVector,Bit>

Returns:

the inverse of the bit vector

See Also:

BitSet.flip(int,int)

nullVector

public BitVector nullVector()

Returns a bit vector of equal dimensionality but containing 0 only.

Specified by:

nullVector in interface NumberVector<BitVector,Bit>

Returns:

a bit vector of equal dimensionality but containing 0 only

plus

public BitVector plus(BitVector fv)

Returns a bit vector corresponding to an XOR operation on this and the specified bit vector.

Specified by:

plus in interface NumberVector<BitVector,Bit>

Parameters:

fv - the bit vector to add

Returns:

a new bit vector corresponding to an XOR operation on this and the specified bit vector

minus

public BitVector minus(BitVector fv)

Returns a bit vector corresponding to an NXOR operation on this and the specified bit vector.

Specified by:

minus in interface NumberVector<BitVector,Bit>

Parameters:

fv - the bit vector to add

Returns:

a new bit vector corresponding to an NXOR operation on this and the specified bit vector

contains

public boolean contains(BitSet bitset)

Returns whether this BitVector contains all bits that are set to true in the specified BitSet.

Parameters:

bitset - the bits to inspect in this BitVector

Returns:

true if this BitVector contains all bits that are set to true in the specified BitSet, false otherwise

getBits

public BitSet getBits()

Returns a copy of the bits currently set in this BitVector.

Returns:

a copy of the bits currently set in this BitVector

toString

public String toString()

Returns a String representation of this BitVector. The representation is suitable to be parsed by BitVectorLabelParser.

Specified by:

toString in interface FeatureVector<BitVector,Bit>

Overrides:

toString in class Object

Returns:

a String representation of the FeatureVector of V

See Also:

Object.toString()

equals

public boolean equals(Object obj)

Indicates whether some other object is "equal to" this BitVector. This BitVector is equal to the given object, if the object is a BitVector of same dimensionality and with identical bits set.

Overrides:

equals in class AbstractNumberVector<BitVector,Bit>

Parameters:

obj - another Object

Returns:

true if the specified Object is an instance of the same runtime class and is of the identical dimensionality and the values of this AbstractNumberVector are equal to the values of obj in all dimensions, respectively

scalarProduct

public Bit scalarProduct(BitVector fv)

Provides the scalar product (inner product) of this BitVector and the given BitVector. As multiplication of Bits, the logical AND operation is used. The result is 0 if the number of bits after the AND operation is a multiple of 2, otherwise the result is 1.

Specified by:

scalarProduct in interface NumberVector<BitVector,Bit>

Parameters:

fv - the BitVector to compute the scalar product for

Returns:

the scalar product (inner product) of this and the given BitVector

newInstance

public BitVector newInstance(double[] values)

Description copied from interface: NumberVector

Returns a new NumberVector of N for the given values.

Specified by:

newInstance in interface NumberVector<BitVector,Bit>

Parameters:

values - the values of the NumberVector

Returns:

a new NumberVector of N for the given values

newInstance

public BitVector newInstance(Vector values)

Description copied from interface: NumberVector

Returns a new NumberVector of N for the given values.

Specified by:

newInstance in interface NumberVector<BitVector,Bit>

Parameters:

values - the values of the NumberVector

Returns:

a new NumberVector of N for the given values

newInstance

public BitVector newInstance(Bit[] values)

Creates and returns a new BitVector based on the passed values.

Specified by:

newInstance in interface FeatureVector<BitVector,Bit>

Parameters:

values - the values of the featureVector

Returns:

a new instance of this BitVector with the specified values

newInstance

public BitVector newInstance(List<Bit> values)

Creates and returns a new BitVector based on the passed values.

Specified by:

newInstance in interface FeatureVector<BitVector,Bit>

Parameters:

values - the values of the featureVector

Returns:

a new instance of this BitVector with the specified values

fromByteBuffer

public BitVector fromByteBuffer(ByteBuffer buffer)
                         throws IOException

Description copied from interface: ByteBufferSerializer

Deserialize an object from a byte buffer (e.g. disk)

Specified by:

fromByteBuffer in interface ByteBufferSerializer<BitVector>

Parameters:

buffer - Data array to process

Returns:

Deserialized object

Throws:

IOException

toByteBuffer

public void toByteBuffer(ByteBuffer buffer,
                         BitVector vec)
                  throws IOException

Description copied from interface: ByteBufferSerializer

Serialize the object to a byte array (e.g. disk)

Specified by:

toByteBuffer in interface ByteBufferSerializer<BitVector>

Parameters:

buffer - Buffer to serialize to

vec - Object to serialize

Throws:

IOException

getByteSize

public int getByteSize(BitVector vec)

Description copied from interface: ByteBufferSerializer

Get the size of the object in bytes.

Specified by:

getByteSize in interface ByteBufferSerializer<BitVector>

Parameters:

vec - Object to serialize

Returns:

maximum size in serialized form
