DoubleIntegerMaxHeap (ELKI: Environment for DeveLoping KDD-Applications Supported by Index-Structures)

java.lang.Object
- de.lmu.ifi.dbs.elki.utilities.datastructures.heap.DoubleIntegerMaxHeap

All Implemented Interfaces:

DoubleIntegerHeap
```
public class DoubleIntegerMaxHeap
extends Object
implements DoubleIntegerHeap
```
Advanced priority queue class, based on a binary heap (for small sizes), which will for larger heaps be accompanied by a 4-ary heap (attached below the root of the two-ary heap, making the root actually 3-ary). This code was automatically instantiated for the types: Double and Integer This combination was found to work quite well in benchmarks, but YMMV. Some other observations from benchmarking:
- Bulk loading did not improve things
- Primitive heaps are substantially faster.
- Since an array in Java has an overhead of 12 bytes, odd-sized object and integer arrays are actually well aligned both for 2-ary and 4-ary heaps.
- Workload makes a huge difference. A load-once, poll-until-empty priority queue is something different than e.g. a top-k heap, which will see a lot of top element replacements.
- Random vs. increasing vs. decreasing vs. sawtooth insertion patterns for top-k make a difference.
- Different day, different benchmark results ...

Nested Class Summary

Nested Classes
Modifier and Type Class and Description

private class DoubleIntegerMaxHeap.UnsortedIter
Unsorted iterator - in heap order.

Nested Classes
Modifier and Type	Class and Description
`private class`	`DoubleIntegerMaxHeap.UnsortedIter` Unsorted iterator - in heap order.

Field Summary

Fields
Modifier and Type	Field and Description
`private static int`	`FOUR_HEAP_INITIAL_SIZE` Initial size of 4-ary heap when initialized. 21 = 4-ary heap of height 2: 1 + 4 + 44 85 = 4-ary heap of height 3: 21 + 444 341 = 4-ary heap of height 4: 85 + 4444 Since we last grew by 255 (to 511), let's use 341.
`protected double[]`	`fourheap` Extension heap.
`protected int[]`	`fourvals` Extension heapvalues.
`protected int`	`modCount` (Structural) modification counter.
`protected int`	`size` Current size of heap.
`private static int`	`TWO_HEAP_INITIAL_SIZE` Initial size of the 2-ary heap.
`private static int`	`TWO_HEAP_MAX_SIZE` Maximum size of the 2-ary heap.
`protected double[]`	`twoheap` Base heap.
`protected int[]`	`twovals` Base heap values.

Constructor Summary

Constructors
Constructor and Description

DoubleIntegerMaxHeap()
Constructor, with default size.

DoubleIntegerMaxHeap(int minsize)
Constructor, with given minimum size.

Constructors
Constructor and Description
`DoubleIntegerMaxHeap()` Constructor, with default size.
`DoubleIntegerMaxHeap(int minsize)` Constructor, with given minimum size.

Method Summary

Methods
Modifier and Type	Method and Description
`void`	`add(double o, int v)` Add a key-value pair to the heap
`void`	`add(double key, int val, int max)` Add a key-value pair to the heap if it improves the top.
`void`	`clear()` Clear the heap contents.
`private void`	`heapifyDown(double reinsert, int val)` Invoke heapify-down for the root object.
`private void`	`heapifyDown2(int twopos, double cur, int val)` Heapify-Down for 2-ary heap.
`private void`	`heapifyDown4(int fourpos, double cur, int val)` Heapify-Down for 4-ary heap.
`private void`	`heapifyUp2(int twopos, double cur, int val)` Heapify-Up method for 2-ary heap.
`private void`	`heapifyUp4(int fourpos, double cur, int val)` Heapify-Up method for 4-ary heap.
`boolean`	`isEmpty()` Is the heap empty?
`double`	`peekKey()` Get the current top key
`int`	`peekValue()` Get the current top value
`void`	`poll()` Remove the first element
`void`	`replaceTopElement(double reinsert, int val)` Combined operation that removes the top element, and inserts a new element instead.
`int`	`size()` Query the size
`String`	`toString()`
`DoubleIntegerMaxHeap.UnsortedIter`	`unsortedIter()` Get an unsorted iterator to inspect the heap.

Methods inherited from class java.lang.Object
clone, equals, finalize, getClass, hashCode, notify, notifyAll, wait, wait, wait

- Field Detail
  - twoheap
```
protected double[] twoheap
```
    Base heap.
  - twovals
```
protected int[] twovals
```
    Base heap values.
  - fourheap
```
protected double[] fourheap
```
    Extension heap.
  - fourvals
```
protected int[] fourvals
```
    Extension heapvalues.
  - size
```
protected int size
```
    Current size of heap.
  - modCount
```
protected int modCount
```
    (Structural) modification counter. Used to invalidate iterators.
  - TWO_HEAP_MAX_SIZE
```
private static final int TWO_HEAP_MAX_SIZE
```
    Maximum size of the 2-ary heap. A complete 2-ary heap has (2^k-1) elements.

    See Also:
    Constant Field Values
  - TWO_HEAP_INITIAL_SIZE
```
private static final int TWO_HEAP_INITIAL_SIZE
```
    Initial size of the 2-ary heap.

    See Also:
    Constant Field Values
  - FOUR_HEAP_INITIAL_SIZE
```
private static final int FOUR_HEAP_INITIAL_SIZE
```
    Initial size of 4-ary heap when initialized. 21 = 4-ary heap of height 2: 1 + 4 + 4*4 85 = 4-ary heap of height 3: 21 + 4*4*4 341 = 4-ary heap of height 4: 85 + 4*4*4*4 Since we last grew by 255 (to 511), let's use 341.

    See Also:
    Constant Field Values
- Constructor Detail
  - DoubleIntegerMaxHeap
```
public DoubleIntegerMaxHeap()
```
    Constructor, with default size.
  - DoubleIntegerMaxHeap
```
public DoubleIntegerMaxHeap(int minsize)
```
    Constructor, with given minimum size.

    Parameters:
    minsize - Minimum size
- Method Detail
  - clear
```
public void clear()
```
    Description copied from interface: DoubleIntegerHeap

    Clear the heap contents.

    Specified by:

    clear in interface DoubleIntegerHeap
  - size
```
public int size()
```
    Description copied from interface: DoubleIntegerHeap

    Query the size

    Specified by:

    size in interface DoubleIntegerHeap

    Returns:
    Size
  - isEmpty
```
public boolean isEmpty()
```
    Description copied from interface: DoubleIntegerHeap

    Is the heap empty?

    Specified by:

    isEmpty in interface DoubleIntegerHeap

    Returns:
    true when the size is 0.
  - add
```
public void add(double o,
       int v)
```
    Description copied from interface: DoubleIntegerHeap

    Add a key-value pair to the heap

    Specified by:

    add in interface DoubleIntegerHeap

    Parameters:
    o - Key
    v - Value
  - add
```
public void add(double key,
       int val,
       int max)
```
    Description copied from interface: DoubleIntegerHeap

    Add a key-value pair to the heap if it improves the top.

    Specified by:

    add in interface DoubleIntegerHeap

    Parameters:
    key - Key
    val - Value
    max - Desired maximum size
  - replaceTopElement
```
public void replaceTopElement(double reinsert,
                     int val)
```
    Description copied from interface: DoubleIntegerHeap

    Combined operation that removes the top element, and inserts a new element instead.

    Specified by:

    replaceTopElement in interface DoubleIntegerHeap

    Parameters:
    reinsert - Key of new element
    val - Value of new element
  - heapifyUp2
```
private void heapifyUp2(int twopos,
              double cur,
              int val)
```
    Heapify-Up method for 2-ary heap.

    Parameters:
    twopos - Position in 2-ary heap.
    cur - Current object
    val - Current value
  - heapifyUp4
```
private void heapifyUp4(int fourpos,
              double cur,
              int val)
```
    Heapify-Up method for 4-ary heap.

    Parameters:
    fourpos - Position in 4-ary heap.
    cur - Current object
    val - Current value
  - poll
```
public void poll()
```
    Description copied from interface: DoubleIntegerHeap

    Remove the first element

    Specified by:

    poll in interface DoubleIntegerHeap
  - heapifyDown
```
private void heapifyDown(double reinsert,
               int val)
```
    Invoke heapify-down for the root object.

    Parameters:
    reinsert - Object to insert.
    val - Value to reinsert.
  - heapifyDown2
```
private void heapifyDown2(int twopos,
                double cur,
                int val)
```
    Heapify-Down for 2-ary heap.

    Parameters:
    twopos - Position in 2-ary heap.
    cur - Current object
    val - Value to reinsert.
  - heapifyDown4
```
private void heapifyDown4(int fourpos,
                double cur,
                int val)
```
    Heapify-Down for 4-ary heap.

    Parameters:
    fourpos - Position in 4-ary heap.
    cur - Current object
    val - Value to reinsert.
  - peekKey
```
public double peekKey()
```
    Description copied from interface: DoubleIntegerHeap

    Get the current top key

    Specified by:

    peekKey in interface DoubleIntegerHeap

    Returns:
    Top key
  - peekValue
```
public int peekValue()
```
    Description copied from interface: DoubleIntegerHeap

    Get the current top value

    Specified by:

    peekValue in interface DoubleIntegerHeap

    Returns:
    Value
  - toString
```
public String toString()
```
    Overrides:

    toString in class Object
  - unsortedIter
```
public DoubleIntegerMaxHeap.UnsortedIter unsortedIter()
```
    Description copied from interface: DoubleIntegerHeap

    Get an unsorted iterator to inspect the heap.

    Specified by:

    unsortedIter in interface DoubleIntegerHeap

    Returns:
    Iterator
