de.lmu.ifi.dbs.elki.visualization.gui

Class ResultVisualizer

java.lang.Object

de.lmu.ifi.dbs.elki.visualization.gui.ResultVisualizer

All Implemented Interfaces:

ResultHandler, ResultProcessor, InspectionUtilFrequentlyScanned, Parameterizable

public class ResultVisualizer
extends Object
implements ResultHandler

Handler to process and visualize a Result.

Nested Class Summary

Nested Classes

Modifier and Type	Class and Description
static class	ResultVisualizer.Parameterizer Parameterization class.

Field Summary

Fields

Modifier and Type	Field and Description
protected static String	DEFAULT_TITLE Default title
protected static Logging	logger Get a logger for this class.
(package private) VisualizerParameterizer	manager Visualization manager.
(package private) boolean	single Single view mode
static OptionID	SINGLE_ID Flag to set single display Key: -vis.single
(package private) String	title Stores the set title.
static OptionID	WINDOW_TITLE_ID Parameter to specify the window title Key: -vis.window.title Default value: "ELKI Result Visualization"

Constructor Summary

Constructors

Constructor and Description
ResultVisualizer(String title, VisualizerParameterizer manager, boolean single) Constructor.

Method Summary

Methods

Modifier and Type	Method and Description
void	processNewResult(HierarchicalResult top, Result result) Process a result.

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Field Detail

logger

protected static final Logging logger

Get a logger for this class.

WINDOW_TITLE_ID

public static final OptionID WINDOW_TITLE_ID

Parameter to specify the window title

Key: -vis.window.title

Default value: "ELKI Result Visualization"

SINGLE_ID

public static final OptionID SINGLE_ID

Flag to set single display

Key: -vis.single

title

String title

Stores the set title.

DEFAULT_TITLE

protected static final String DEFAULT_TITLE

Default title

See Also:

Constant Field Values

manager

VisualizerParameterizer manager

Visualization manager.

single

boolean single

Single view mode

Constructor Detail

ResultVisualizer

public ResultVisualizer(String title,
                VisualizerParameterizer manager,
                boolean single)

Constructor.

Parameters:

title - Window title

manager - Parameterization manager for visualizers

single - Flag to indicat single-view mode.

Method Detail

processNewResult

public void processNewResult(HierarchicalResult top,
                    Result result)

Description copied from interface: ResultProcessor

Process a result.

Specified by:

processNewResult in interface ResultProcessor

Parameters:

top - The base of the result tree.

result - Newly added result subtree.
