OnDiskArray (ELKI: Environment for DeveLoping KDD-Applications Supported by Index-Structures)

java.lang.Object
- de.lmu.ifi.dbs.elki.persistent.OnDiskArray

All Implemented Interfaces:

Serializable
```
public class OnDiskArray
extends Object
implements Serializable
```
On Disc Array storage for records of a given size. This can be used to implement various fixed size record-based data structures. The file format is designed to have a fixed-size header followed by the actual data.

See Also:
Serialized Form

Field Summary

Fields
Modifier and Type	Field and Description
`private RandomAccessFile`	`file` Random Access File object.
`private File`	`filename` File name.
`private static int`	`HEADER_POS_SIZE` Position of file size (in records)
`private int`	`headersize` Size of the header in the file.
`private static int`	`INTERNAL_HEADER_SIZE` Size of the classes header size.
`private FileLock`	`lock` Lock for the file that will be kept while writing.
`protected int`	`magic` Magic number used to identify files
`private MappedByteBuffer`	`map`
`private int`	`numrecs` Number of records in the file.
`private int`	`recordsize` Size of the records in the file.
`private static long`	`serialVersionUID` Serial version.
`private boolean`	`writable` Writable or read-only object

Constructor Summary

Constructors
Constructor and Description
`OnDiskArray(File filename, int magicseed, int extraheadersize, boolean writable)` Constructor to open an existing file.
`OnDiskArray(File filename, int magicseed, int extraheadersize, int recordsize, boolean writable)` Constructor to open an existing file.
`OnDiskArray(File filename, int magicseed, int extraheadersize, int recordsize, int initialsize)` Constructor to write a new file.

Method Summary

Methods
Modifier and Type	Method and Description
`void`	`close()` Explicitly close the file.
`void`	`ensureSize(int size)` Ensure that the file can fit the given number of records.
`ByteBuffer`	`getExtraHeader()` Read the extra header data.
`protected int`	`getExtraHeaderSize()` Return the size of the extra header.
`File`	`getFilename()` Get the file name.
`int`	`getNumRecords()` Get number of records in file.
`ByteBuffer`	`getRecordBuffer(int index)` Get a record buffer
`protected int`	`getRecordsize()` Get the size of a single record.
`private long`	`indexToFileposition(long index)` Compute file position from index number
`boolean`	`isWritable()` Check if the file is writable.
`private void`	`mapArray()` (Re-) map the data array.
`static int`	`mixMagic(int magic1, int magic2)` Mix two magic numbers into one, to obtain a combined magic.
`void`	`resizeFile(int newsize)` Resize file to the intended size
`private void`	`validateHeader(boolean validateRecordSize)` Validates the header and throws an IOException if the header is invalid.

Methods inherited from class java.lang.Object
clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

- Field Detail
  - serialVersionUID
```
private static final long serialVersionUID
```
    Serial version. NOTE: Change this version whenever the file structure is changed in an incompatible way: This will modify the file magic, and thus prevent applications from reading incompatible files.

    See Also:
    Constant Field Values
  - magic
```
protected int magic
```
    Magic number used to identify files
  - headersize
```
private int headersize
```
    Size of the header in the file. Note that the internal header is four integers already.
  - recordsize
```
private int recordsize
```
    Size of the records in the file.
  - numrecs
```
private int numrecs
```
    Number of records in the file.
  - filename
```
private File filename
```
    File name.
  - file
```
private final RandomAccessFile file
```
    Random Access File object.
  - lock
```
private FileLock lock
```
    Lock for the file that will be kept while writing.
  - writable
```
private boolean writable
```
    Writable or read-only object
  - map
```
private MappedByteBuffer map
```
  - INTERNAL_HEADER_SIZE
```
private static final int INTERNAL_HEADER_SIZE
```
    Size of the classes header size.

    See Also:
    Constant Field Values
  - HEADER_POS_SIZE
```
private static final int HEADER_POS_SIZE
```
    Position of file size (in records)

    See Also:
    Constant Field Values
- Constructor Detail
  - OnDiskArray
```
public OnDiskArray(File filename,
           int magicseed,
           int extraheadersize,
           int recordsize,
           int initialsize)
            throws IOException
```
    Constructor to write a new file.

    Parameters:
    filename - File name to be opened.
    magicseed - Magic number to derive real magic from.
    extraheadersize - header size NOT including the internal header
    recordsize - Record size
    initialsize - Initial file size (in records)

    Throws:

    IOException - on IO errors
  - OnDiskArray
```
public OnDiskArray(File filename,
           int magicseed,
           int extraheadersize,
           int recordsize,
           boolean writable)
            throws IOException
```
    Constructor to open an existing file. The provided record size must match the record size stored within the files header. If you don't know this size yet and/or need to access the extra header you should use the other constructor below

    Parameters:
    filename - File name to be opened.
    magicseed - Magic number to derive real magic from.
    extraheadersize - header size NOT including the internal header
    recordsize - Record size
    writable - flag to open the file writable

    Throws:

    IOException - on IO errors
  - OnDiskArray
```
public OnDiskArray(File filename,
           int magicseed,
           int extraheadersize,
           boolean writable)
            throws IOException
```
    Constructor to open an existing file. The record size is read from the file's header and can be obtained by getRecordsize()

    Parameters:
    filename - File name to be opened.
    magicseed - Magic number to derive real magic from.
    extraheadersize - header size NOT including the internal header
    writable - flag to open the file writable

    Throws:

    IOException - on IO errors
- Method Detail
  - mapArray
```
private void mapArray()
               throws IOException
```
    (Re-) map the data array.

    Throws:

    IOException - on mapping error.
  - validateHeader
```
private void validateHeader(boolean validateRecordSize)
                     throws IOException
```
    Validates the header and throws an IOException if the header is invalid. If validateRecordSize is set to true the record size must match exactly the stored record size within the files header, else the record size is read from the header and used.

    Parameters:
    validateRecordSize -

    Throws:

    IOException
  - mixMagic
```
public static final int mixMagic(int magic1,
           int magic2)
```
    Mix two magic numbers into one, to obtain a combined magic. Note: mixMagic(a,b) != mixMagic(b,a) usually.

    Parameters:
    magic1 - Magic number to mix.
    magic2 - Magic number to mix.

    Returns:
    Mixed magic number.
  - indexToFileposition
```
private long indexToFileposition(long index)
```
    Compute file position from index number

    Parameters:
    index - Index offset

    Returns:
    file position
  - resizeFile
```
public void resizeFile(int newsize)
                throws IOException
```
    Resize file to the intended size

    Parameters:
    newsize - New file size.

    Throws:

    IOException - on IO errors
  - getRecordBuffer
```
public ByteBuffer getRecordBuffer(int index)
                           throws IOException
```
    Get a record buffer

    Parameters:
    index - Record index

    Returns:
    Byte buffer for the record

    Throws:

    IOException - on IO errors
  - getExtraHeaderSize
```
protected int getExtraHeaderSize()
```
    Return the size of the extra header. Accessor.

    Returns:
    Extra header size
  - getExtraHeader
```
public ByteBuffer getExtraHeader()
                          throws IOException
```
    Read the extra header data.

    Returns:
    additional header data

    Throws:

    IOException - on IO errors
  - getRecordsize
```
protected int getRecordsize()
```
    Get the size of a single record.

    Returns:
    Record size.
  - getFilename
```
public File getFilename()
```
    Get the file name.

    Returns:
    File name
  - isWritable
```
public boolean isWritable()
```
    Check if the file is writable.

    Returns:
    true if the file is writable.
  - close
```
public void close()
           throws IOException
```
    Explicitly close the file. Note: following operations will likely cause IOExceptions.

    Throws:

    IOException - on IO errors
  - getNumRecords
```
public int getNumRecords()
```
    Get number of records in file.

    Returns:
    Number of records in the file.
  - ensureSize
```
public void ensureSize(int size)
                throws IOException
```
    Ensure that the file can fit the given number of records.

    Parameters:
    size - Size

    Throws:

    IOException
